The HC06A01KNX environmental sensor is a device from the KNX 9025 series, is wall-mounted and is completed by a black or white glass.
Contact our team to get all your questions answered
The device integrates humidity and temperature sensors. It also has a 2-way connector on the rear side that can be configured as a digital or analogue input; in fact, it is possible to connect an additional NTC probe (Eelectron code TS01A01ACC or TS01B01ACC – not included) to the device to obtain a second temperature measurement. The device includes 2 2-stage thermostats for the control of two distinct areas, both with integrated PI controller for driving heating and cooling equipment, valves, 6-way valves, 2 and 4-pipe fan coils, etc.
The humidity sensor manages the reading of the relative humidity of the environment and allows the control of humidification and dehumidification devices at thresholds with hysteresis. The device integrates 6 capacitive keys for the management of on/off commands, dimmers, shutters and blinds, execution and learning of scenarios, sequences of objects, local thermostat controls, etc.
The device includes an RGB LED on the front for displaying statuses or other quantities available on the KNX bus.
The device can be installed on an Italian 2-module box, on a German or English box. The device includes the KNX communication interface.
For a better experience, rotate the screen horizontally.
| Code | Image | Type | Color | Channels |
|---|---|---|---|---|
| HC06A01KNX-1 |
|
BUTTONS
|
WHITE
|
8 |
| HC06A01KNX-3 |
|
BUTTONS
|
BLACK
|
8 |
| 9025GH06L01 |
|
COVER |
WHITE
|
- |
| 9025GH06L03 |
|
COVER |
BLACK
|
- |
